REC Tyre Changer - TC 200
- Automatic tilting type tyre changer which helps in increasing the productivity.
- The alignment of the mounting tool with respect the centre of the rim always irrespective of the rim size, helps in mounting the tyres at ease.
- The heavy duty Bead press cylinder with a force of 3125 kgf/cm2, makes the job easier when dealing with tough High performance tyres and RFt tyres.
- Weighing at least 30 % more than the competitors, it is built for rough handling and for longer life.
- Has the capacity to handle upto 24 “ rim size.
- The machine can be upgraded to TC300 by fitting the help arm ( RFT Kit).
- It can also be upgraded to leverless tyre changer by fitting the automatic tooling device.
| Working Type | TILTING |
| Upgradable to Higher Model | YES |
| Rim Outer Clamping | 10 - 23 " |
| Rim Inner Clamping | 12 - 24 " |
| Bead Breaking Power | 3125 kgs/cm² |
| Max. Wheel Width | 17 " ( 432 mm) |
| Max. Wheel Diameter | 41 " ( 1040 mm) |
| Motor | 1 HP |
| Electrical Input | 220 V, 1 PH, 50 hz |
| Air Pressure Required | 7 - 9 BARS |
| Dimensions in MM | 1607 mm |
| Width | 930 mm |
| Length | 2300 mm |
| Nett Weight | 255 kgs |
